Sensing Channel 4-channel
Sensing distance 40mm
Sensing target Opaquematerial of min. Ø4mm
Light source Infrared LED(940nm)
Response time Max. 1ms
Power supply 18-35VDC ±10%(ripple P-P: max. 10%)
Current consumption Max. 50mA
Sensitivity adjustment Fixed
Operation mode Dark ON
Control output NPN open collector(individual 4 outputs)
Connection type Cable type(Ø6, 4m)
Environment_Ambient illumination Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature -25 to 65℃, storage: -25 to 70℃
Protection structure IP65
Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH
Material Case, Cover: ABS
Bracket H01/H04(G01)
Weight Approx. 1.5kg(approx. 500g)
